#include <dict0mem.h>
Data structure for a database table. Most fields will be
initialized to 0, NULL or FALSE in dict_mem_table_create().
Definition at line 721 of file dict0mem.h.
| ib_uint64_t dict_table_t::autoinc |
autoinc counter value to give to the next inserted row
Definition at line 949 of file dict0mem.h.
| lock_t* dict_table_t::autoinc_lock |
!< The following fields are used by the AUTOINC code. The actual collection of tables locked during AUTOINC read/write is kept in trx_t. In order to quickly determine whether a transaction has locked the AUTOINC lock we keep a pointer to the transaction here in the autoinc_trx variable. This is to avoid acquiring the lock_sys_t::mutex and scanning the vector in trx_t.
When an AUTOINC lock has to wait, the corresponding lock instance is created on the trx lock heap rather than use the pre-allocated instance in autoinc_lock below. a buffer for an AUTOINC lock for this table: we allocate the memory here so that individual transactions can get it and release it without a need to allocate space from the lock heap of the trx: otherwise the lock heap would grow rapidly if we do a large insert from a select
Definition at line 939 of file dict0mem.h.
| ib_mutex_t dict_table_t::autoinc_mutex |
mutex protecting the autoincrement counter
Definition at line 947 of file dict0mem.h.
| const trx_t* dict_table_t::autoinc_trx |
The transaction that currently holds the the AUTOINC lock on this table. Protected by lock_sys->mutex.
Definition at line 961 of file dict0mem.h.
| unsigned dict_table_t::big_rows |
flag: TRUE if the maximum length of a single row exceeds BIG_ROW_SIZE; initialized in dict_table_add_to_cache()
Definition at line 827 of file dict0mem.h.
| unsigned dict_table_t::cached |
TRUE if the table object has been added to the dictionary cache
Definition at line 743 of file dict0mem.h.
| unsigned dict_table_t::can_be_evicted |
TRUE if it's not an InnoDB system table or a table that has no FK relationships
Definition at line 756 of file dict0mem.h.
| const char* dict_table_t::col_names |
Column names packed in a character string "name1\0name2\0...nameN\0". Until the string contains n_cols, it will be allocated from a temporary heap. The final string will be allocated from table->heap.
Definition at line 766 of file dict0mem.h.
| dict_col_t* dict_table_t::cols |
array of column descriptions
Definition at line 764 of file dict0mem.h.
| unsigned dict_table_t::corrupted |
TRUE if table is corrupted
Definition at line 759 of file dict0mem.h.
| char* dict_table_t::data_dir_path |
NULL or the directory path specified by DATA DIRECTORY
Definition at line 731 of file dict0mem.h.
| trx_id_t dict_table_t::def_trx_id |
transaction id that last touched the table definition, either when loading the definition or CREATE TABLE, or ALTER TABLE (prepare, commit, and rollback phases)
Definition at line 798 of file dict0mem.h.
| const char* dict_table_t::dir_path_of_temp_table |
NULL or the directory path where a TEMPORARY table that was explicitly created by a user should be placed if innodb_file_per_table is defined in my.cnf; in Unix this is usually /tmp/..., in Windows temp...
Definition at line 725 of file dict0mem.h.
| unsigned dict_table_t::drop_aborted |
TRUE if some indexes should be dropped after ONLINE_INDEX_ABORTED or ONLINE_INDEX_ABORTED_DROPPED
Definition at line 761 of file dict0mem.h.
| unsigned dict_table_t::fk_max_recusive_level |
maximum recursive level we support when loading tables chained together with FK constraints. If exceeds this level, we will stop loading child table into memory along with its parent table
Definition at line 786 of file dict0mem.h.
| unsigned dict_table_t::flags |
DICT_TF_...
Definition at line 736 of file dict0mem.h.
| unsigned dict_table_t::flags2 |
DICT_TF2_...
Definition at line 737 of file dict0mem.h.
| dict_table_t::foreign_list |
list of foreign key constraints in the table; these refer to columns in other tables
Definition at line 777 of file dict0mem.h.
| mem_heap_t* dict_table_t::heap |
memory heap
Definition at line 723 of file dict0mem.h.
| unsigned dict_table_t::ibd_file_missing |
TRUE if this is in a single-table tablespace and the .ibd file is missing; then we must return in ha_innodb.cc an error if the user tries to query such an orphaned table
Definition at line 739 of file dict0mem.h.
| table_id_t dict_table_t::id |
id of the table
Definition at line 722 of file dict0mem.h.
| hash_node_t dict_table_t::id_hash |
hash chain node
Definition at line 773 of file dict0mem.h.
| dict_table_t::indexes |
list of indexes of the table
Definition at line 775 of file dict0mem.h.
| dict_table_t::locks |
list of locks on the table; protected by lock_sys->mutex
Definition at line 987 of file dict0mem.h.
| unsigned dict_table_t::n_cols |
number of columns
Definition at line 754 of file dict0mem.h.
| unsigned dict_table_t::n_def |
number of columns defined so far
Definition at line 753 of file dict0mem.h.
| ulint dict_table_t::n_foreign_key_checks_running |
count of how many foreign key check operations are currently being performed on the table: we cannot drop the table while there are foreign key checks running on it!
Definition at line 792 of file dict0mem.h.
| ulint dict_table_t::n_rec_locks |
Count of the number of record locks on this table. We use this to determine whether we can evict the table from the dictionary cache. It is protected by lock_sys->mutex.
Definition at line 976 of file dict0mem.h.
| ulint dict_table_t::n_ref_count |
count of how many handles are opened to this table; dropping of the table is NOT allowed until this count gets to zero; MySQL does NOT itself check the number of open handles at drop
Definition at line 981 of file dict0mem.h.
| ulong dict_table_t::n_waiting_or_granted_auto_inc_locks |
This counter is used to track the number of granted and pending autoinc locks on this table. This value is set after acquiring the lock_sys_t::mutex but we peek the contents to determine whether other transactions have acquired the AUTOINC lock or not. Of course only one transaction can be granted the lock but there can be multiple waiters.
Definition at line 952 of file dict0mem.h.
| char* dict_table_t::name |
table name
Definition at line 724 of file dict0mem.h.
| hash_node_t dict_table_t::name_hash |
hash chain node
Definition at line 772 of file dict0mem.h.
| trx_id_t dict_table_t::query_cache_inv_trx_id |
transactions whose trx id is smaller than this number are not allowed to store to the MySQL query cache or retrieve from it; when a trx with undo logs commits, it sets this to the value of the trx id counter for the tables it had an IX lock on
Definition at line 804 of file dict0mem.h.
| ib_quiesce_t dict_table_t::quiesce |
Quiescing states, protected by the dict_index_t::lock. ie. we can only change the state if we acquire all the latches (dict_index_t::lock) in X mode of this table's indexes.
Definition at line 968 of file dict0mem.h.
| dict_table_t::referenced_list |
list of foreign key constraints which refer to this table
Definition at line 781 of file dict0mem.h.
| unsigned dict_table_t::space |
space where the clustered index of the table is placed
Definition at line 734 of file dict0mem.h.
| ulint dict_table_t::stat_clustered_index_size |
approximate clustered index size in database pages
Definition at line 887 of file dict0mem.h.
| unsigned dict_table_t::stat_initialized |
Statistics for query optimization TRUE if statistics have been calculated the first time after database startup or table creation
Definition at line 832 of file dict0mem.h.
| ib_uint64_t dict_table_t::stat_modified_counter |
when a row is inserted, updated, or deleted, we add 1 to this number; we calculate new estimates for the stat_... values for the table and the indexes when about 1 / 16 of table has been modified; also when the estimate operation is called for MySQL SHOW TABLE STATUS; the counter is reset to zero at statistics calculation; this counter is not protected by any latch, because this is only used for heuristics
Definition at line 892 of file dict0mem.h.
| ib_uint64_t dict_table_t::stat_n_rows |
approximate number of rows in the table; we periodically calculate new estimates
Definition at line 884 of file dict0mem.h.
| ib_uint32_t dict_table_t::stat_persistent |
The two bits below are set in the ::stat_persistent member and have the following meaning:
Definition at line 838 of file dict0mem.h.
| ulint dict_table_t::stat_sum_of_other_index_sizes |
other indexes in database pages
Definition at line 890 of file dict0mem.h.
| ib_uint32_t dict_table_t::stats_auto_recalc |
The two bits below are set in the ::stats_auto_recalc member and have the following meaning:
Definition at line 857 of file dict0mem.h.
| byte dict_table_t::stats_bg_flag |
see BG_STAT_* above. Writes are covered by dict_sys->mutex. Dirty reads are possible.
Definition at line 918 of file dict0mem.h.
| ib_time_t dict_table_t::stats_last_recalc |
Timestamp of last recalc of the stats
Definition at line 836 of file dict0mem.h.
| ulint dict_table_t::stats_sample_pages |
the number of pages to sample for this table during persistent stats estimation; if this is 0, then the value of the global srv_stats_persistent_sample_pages will be used instead.
Definition at line 878 of file dict0mem.h.
| dict_table_t::table_LRU |
node of the LRU list of tables
Definition at line 784 of file dict0mem.h.
| unsigned dict_table_t::to_be_dropped |
TRUE if the table is to be dropped, but not yet actually dropped (could in the bk drop list); It is turned on at the beginning of row_drop_table_for_mysql() and turned off just before we start to update system tables for the drop. It is protected by dict_operation_lock
Definition at line 746 of file dict0mem.h.
