This graph shows which files directly or indirectly include this file:

Macros
#define	COL_OBJECT_SCHEMA_SIZE 64
#define	COL_OBJECT_NAME_EXTENDED_SIZE 512
#define	COL_OBJECT_NAME_SIZE 64
#define	COL_INDEX_NAME_SIZE 64
#define	COL_INFO_SIZE 1024
#define	COL_SOURCE_SIZE 64
#define	COL_DIGEST_SIZE 64
#define	COL_DIGEST_TEXT_SIZE 1024
#define	FIRST_TIMER_NAME (static_cast<int> (TIMER_NAME_CYCLE))
#define	LAST_TIMER_NAME (static_cast<int> (TIMER_NAME_TICK))
#define	COUNT_TIMER_NAME (LAST_TIMER_NAME - FIRST_TIMER_NAME + 1)
#define	FIRST_OPERATION_TYPE (static_cast<int> (OPERATION_TYPE_LOCK))
#define	LAST_OPERATION_TYPE (static_cast<int> (OPERATION_TYPE_IDLE))
#define	COUNT_OPERATION_TYPE (LAST_OPERATION_TYPE - FIRST_OPERATION_TYPE + 1)
#define	FIRST_OBJECT_TYPE (static_cast<int> (OBJECT_TYPE_TABLE))
#define	LAST_OBJECT_TYPE (static_cast<int> (OBJECT_TYPE_TEMPORARY_TABLE))
#define	COUNT_OBJECT_TYPE (LAST_OBJECT_TYPE - FIRST_OBJECT_TYPE + 1)
#define	FIRST_EVENT_TYPE (static_cast<int> (EVENT_TYPE_STATEMENT))
#define	LAST_EVENT_TYPE (static_cast<int> (EVENT_TYPE_WAIT))
#define	COUNT_EVENT_TYPE (LAST_EVENT_TYPE - FIRST_EVENT_TYPE + 1)

Enumerations
enum	enum_timer_name { TIMER_NAME_CYCLE = 1, TIMER_NAME_NANOSEC = 2, TIMER_NAME_MICROSEC = 3, TIMER_NAME_MILLISEC = 4, TIMER_NAME_TICK = 5 }
enum	enum_yes_no { ENUM_YES = 1, ENUM_NO = 2 }
enum	enum_operation_type { OPERATION_TYPE_LOCK = 1, OPERATION_TYPE_TRYLOCK = 2, OPERATION_TYPE_READLOCK = 3, OPERATION_TYPE_WRITELOCK = 4, OPERATION_TYPE_TRYREADLOCK = 5, OPERATION_TYPE_TRYWRITELOCK = 6, OPERATION_TYPE_WAIT = 7, OPERATION_TYPE_TIMEDWAIT = 8, OPERATION_TYPE_FILECREATE = 9, OPERATION_TYPE_FILECREATETMP = 10, OPERATION_TYPE_FILEOPEN = 11, OPERATION_TYPE_FILESTREAMOPEN = 12, OPERATION_TYPE_FILECLOSE = 13, OPERATION_TYPE_FILESTREAMCLOSE = 14, OPERATION_TYPE_FILEREAD = 15, OPERATION_TYPE_FILEWRITE = 16, OPERATION_TYPE_FILESEEK = 17, OPERATION_TYPE_FILETELL = 18, OPERATION_TYPE_FILEFLUSH = 19, OPERATION_TYPE_FILESTAT = 20, OPERATION_TYPE_FILEFSTAT = 21, OPERATION_TYPE_FILECHSIZE = 22, OPERATION_TYPE_FILEDELETE = 23, OPERATION_TYPE_FILERENAME = 24, OPERATION_TYPE_FILESYNC = 25, OPERATION_TYPE_TABLE_FETCH = 26, OPERATION_TYPE_TABLE_WRITE_ROW = 27, OPERATION_TYPE_TABLE_UPDATE_ROW = 28, OPERATION_TYPE_TABLE_DELETE_ROW = 29, OPERATION_TYPE_TL_READ_NORMAL = 30, OPERATION_TYPE_TL_READ_WITH_SHARED_LOCKS = 31, OPERATION_TYPE_TL_READ_HIGH_PRIORITY = 32, OPERATION_TYPE_TL_READ_NO_INSERTS = 33, OPERATION_TYPE_TL_WRITE_ALLOW_WRITE = 34, OPERATION_TYPE_TL_WRITE_CONCURRENT_INSERT = 35, OPERATION_TYPE_TL_WRITE_DELAYED = 36, OPERATION_TYPE_TL_WRITE_LOW_PRIORITY = 37, OPERATION_TYPE_TL_WRITE_NORMAL = 38, OPERATION_TYPE_TL_READ_EXTERNAL = 39, OPERATION_TYPE_TL_WRITE_EXTERNAL = 40, OPERATION_TYPE_SOCKETCREATE = 41, OPERATION_TYPE_SOCKETCONNECT = 42, OPERATION_TYPE_SOCKETBIND = 43, OPERATION_TYPE_SOCKETCLOSE = 44, OPERATION_TYPE_SOCKETSEND = 45, OPERATION_TYPE_SOCKETRECV = 46, OPERATION_TYPE_SOCKETSENDTO = 47, OPERATION_TYPE_SOCKETRECVFROM = 48, OPERATION_TYPE_SOCKETSENDMSG = 49, OPERATION_TYPE_SOCKETRECVMSG = 50, OPERATION_TYPE_SOCKETSEEK = 51, OPERATION_TYPE_SOCKETOPT = 52, OPERATION_TYPE_SOCKETSTAT = 53, OPERATION_TYPE_SOCKETSHUTDOWN = 54, OPERATION_TYPE_SOCKETSELECT = 55, OPERATION_TYPE_IDLE = 56 }
enum	enum_object_type { OBJECT_TYPE_TABLE = 1, OBJECT_TYPE_TEMPORARY_TABLE = 2 }
enum	enum_event_type { EVENT_TYPE_STATEMENT = 1, EVENT_TYPE_STAGE = 2, EVENT_TYPE_WAIT = 3 }

Detailed Description

Data types for columns used in the performance schema tables (declarations)

Definition in file pfs_column_types.h.

Macro Definition Documentation

#define COL_DIGEST_SIZE 64

Size of the DIGEST columns.

Definition at line 57 of file pfs_column_types.h.

#define COL_DIGEST_TEXT_SIZE 1024

Size of the DIGEST_TEXT columns.

Definition at line 60 of file pfs_column_types.h.

#define COL_INDEX_NAME_SIZE 64

Size of the INDEX_NAME columns.

Definition at line 42 of file pfs_column_types.h.

#define COL_INFO_SIZE 1024

Size of INFO columns. Size in bytes of:

performance_schema.events_statement_current (INFO)
performance_schema.events_statement_history (INFO)
performance_schema.events_statement_history_long (INFO)

Definition at line 51 of file pfs_column_types.h.

#define COL_OBJECT_NAME_EXTENDED_SIZE 512

Size of the extended OBJECT_NAME columns. 'Extended' columns are used when the object name also represents the name of a non SQL object, such as a file name. Size in bytes of:
